Inductores fijos
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo | Material - Núcleo | Inductancia | Tolerancia | Clasificación de corriente (amperios) | Corriente - Saturación (Isat) | Blindaje | Resistencia de CC (DCR) | Q a frecuencia | Frecuencia: autorresonante | Clasificaciones | Temperatura de funcionamiento | Frecuencia de inductancia - Prueba | Características | Tipo de montaje | Proveedor Dispositivo Paquete | Tamaño/Dimensión | Altura - Asentado (Máx.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNL252018QF-330JFIXED IND 33UH 110MA 7.1OHM SMD |
1,740 |
|
Tabla de datos |
SNL252018QF | 1008 (2520 Metric) | Cut Tape (CT) | Active | Wirewound | Ferrite | 33 µH | ±5% | 110 mA | - | Unshielded | 7.1Ohm Max | 25 @ 2.52MHz | 20MHz | - | -40°C ~ 125°C | 2.52 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.075" (1.90mm) |
|
MLF2012C330MT000FIXED IND 33UH 5MA 1.1 OHM SMD |
1,606 |
|
Tabla de datos |
MLF | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Multilayer | Ferrite | 33 µH | ±20% | 5 mA | - | Shielded | 1.1Ohm Max | - | 15MHz | - | -40°C ~ 85°C | 400 kHz | - | Surface Mount | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
PTL2012-F68NTINDUCTOR PHOTOLITHOGRAPHIC 68NH |
1,024 |
|
Tabla de datos |
PTL2012F | 0805 (2012 Metric) | Cut Tape (CT) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.026" (0.65mm) |
|
ELJ-QF18NJFFIXED IND 18NH 240MA 700MOHM SMD |
10,000 |
|
Tabla de datos |
QF | 0402 (1005 Metric) | Bulk | Obsolete | Multilayer | Ceramic | 18 nH | ±5% | 240 mA | - | Unshielded | 700mOhm Max | 10 @ 100MHz | 2.2GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
WRFI0805-S-43NJT-CTWirewound RF Inductor,0805,43nH, |
7,120 |
|
Tabla de datos |
WRFI | 0805 (2012 Metric) | Strip | Active | Wirewound | Ceramic | 43 nH | ±5% | 500 mA | - | - | 340mOhm | 60 @ 500MHz | 1.65GHz | - | -40°C ~ 125°C | 200 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
|
|
WRFI0603-S-R11JT-CTWirewound RF Inductor,0603,110nH |
5,900 |
|
Tabla de datos |
WRFI | 0603 (1608 Metric) | Strip | Active | Wirewound | Ceramic | 110 nH | ±5% | 300 mA | - | - | 610mOhm | 32 @ 150MHz | 1.35GHz | - | -40°C ~ 125°C | 150 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
WRFI0603-S-R14JT-CTWirewound RF Inductor,0603,140nH |
5,900 |
|
Tabla de datos |
WRFI | 0603 (1608 Metric) | Strip | Active | Wirewound | Ceramic | 140 nH | ±5% | 280 mA | - | - | 870mOhm | 28 @ 100MHz | 1.3GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
WRFI0603-S-56NJT-CTWirewound RF Inductor,0603,56nH, |
5,900 |
|
Tabla de datos |
WRFI | 0603 (1608 Metric) | Strip | Active | Wirewound | Ceramic | 56 nH | ±5% | 600 mA | - | - | 310mOhm | 38 @ 200MHz | 1.9GHz | - | -40°C ~ 125°C | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
WRFI0805-S-47NJT-CTWirewound RF Inductor,0805,47nH, |
5,620 |
|
Tabla de datos |
WRFI | 0805 (2012 Metric) | Strip | Active | Wirewound | Ceramic | 47 nH | ±5% | 500 mA | - | - | 310mOhm | 60 @ 500MHz | 1.65GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
|
|
WRFI0805-S-56NJT-CTWirewound RF Inductor,0805,56nH, |
1,420 |
|
Tabla de datos |
WRFI | 0805 (2012 Metric) | Strip | Active | Wirewound | Ceramic | 56 nH | ±5% | 500 mA | - | - | 340mOhm | 60 @ 500MHz | 1.55GHz | - | -40°C ~ 125°C | 200 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
|
ASPI-4020S-6R2M-TFIXED IND 6.2UH 1.08A 115MOHM SM |
3,000 |
|
Tabla de datos |
ASPI-4020S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.2 µH | ±20% | 1.08 A | 2.15A | Shielded | 115mOhm | - | 36MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.079" (2.00mm) |
.jpg)
|
HFI-100505-10NJFIXED IND 10NH 300MA 420MOHM SMD |
20,194 |
|
Tabla de datos |
HFI | 0402 (1005 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | Drum Core, Wirewound | Ceramic | 10 nH | ±5% | 300 mA | - | Unshielded | 420mOhm Max | 8 @ 100MHz | 3.2GHz | - | - | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
HFI-100505-3N3SFIXED IND 3.3NH 300MA 190MOHM SM |
15,033 |
|
Tabla de datos |
HFI | 0402 (1005 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | Drum Core, Wirewound | Ceramic | 3.3 nH | ±0.3nH | 300 mA | - | Unshielded | 190mOhm Max | 8 @ 100MHz | 6GHz | - | - | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
MHQ0603P27NHTD25FIXED IND 27NH 160MA 2.2 OHM SMD |
14,995 |
|
Tabla de datos |
MHQ-P | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic, Non-Magnetic | 27 nH | ±3% | 160 mA | - | Unshielded | 2.2Ohm Max | 16 @ 500MHz | 2GHz | AEC-Q200 | -55°C ~ 125°C | 500 MHz | - | Surface Mount | 0201 (0603 Metric) | 0.026" L x 0.014" W (0.65mm x 0.35mm) | 0.016" (0.40mm) |
|
|
HFI-100505-2N7SFIXED IND 2.7NH 300MA 170MOHM SM |
12,300 |
|
Tabla de datos |
HFI | 0402 (1005 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | Drum Core, Wirewound | Ceramic | 2.7 nH | ±0.3nH | 300 mA | - | Unshielded | 170mOhm Max | 8 @ 100MHz | 6GHz | - | - | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
.jpg)
|
LQG15HH2N2C02DFIXED IND 2.2NH 900MA 0.09OHM SM |
10,000 |
|
Tabla de datos |
LQG15 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Air | 2.2 nH | ±0.2nH | 900 mA | - | Unshielded | 90mOhm Max | 8 @ 100MHz | 6GHz | AEC-Q200 | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
LQG15HH82NH02DFIXED IND 82NH 200MA 1.2OHM SMD |
9,750 |
|
Tabla de datos |
LQG15 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Air | 82 nH | ±3% | 200 mA | - | Unshielded | 1.2Ohm Max | 8 @ 100MHz | 700MHz | AEC-Q200 | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
HFI-100505-2N2SFIXED IND 2.2NH 300MA 160MOHM SM |
9,059 |
|
Tabla de datos |
HFI | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | Wirewound | Ceramic | 2.2 nH | ±0.3nH | 300 mA | - | Unshielded | 160mOhm Max | 8 @ 100MHz | 6GHz | - | - | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
0402HS-240EGTSFIXED IND 24NH 400MA 300MOHM SMD |
7,907 |
|
Tabla de datos |
0402HS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 24 nH | ±2% | 400 mA | - | Unshielded | 300mOhm | 25 @ 250MHz | 2.7GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.050" L x 0.030" W (1.27mm x 0.76mm) | 0.024" (0.60mm) |
|
0402HM-240EGTSFIXED IND 24NH 280MA 520MOHM SMD |
7,885 |
|
Tabla de datos |
0402HM | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 24 nH | ±2% | 280 mA | - | Unshielded | 520mOhm | 25 @ 250MHz | 3.5GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.045" L x 0.028" W (1.15mm x 0.70mm) | 0.024" (0.60mm) |
