FET, MOSFET
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo FET | Tecnología | Voltaje de drenaje a fuente (Vdss) | Corriente: drenaje continuo (Id) a 25 °C | Voltaje de excitación (máx. Rds activado, mín. Rds activado) | Rds activado (máx.) a Id, Vgs | Vgs(th) (máx.) a Id | Carga de compuerta (Qg) (máx.) a Vgs | Vgs (máx.) | Capacitancia de entrada (Ciss) (máx.) a Vds | Característica FET | Disipación de potencia (máx.) | Temperatura de funcionamiento | Grado | Calificación | Tipo de montaje | Proveedor Dispositivo Paquete |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DMP3028LFDEQ-7MOSFET BVDSS: 25V~30V U-DFN2020- |
4,494 |
|
Tabla de datos |
- | 6-PowerUDFN | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 6.8A (Ta) | 4.5V, 10V | 25mOhm @ 7A, 10V | 2.4V @ 250µA | 33 nC @ 10 V | ±20V | 1860 pF @ 15 V | - | 660mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | U-DFN2020-6 (Type E) |
|
NTR4503NT3MOSFET N-CH 30V 1.5A SOT23-3 |
3,184 |
|
Tabla de datos |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 1.5A (Ta) | 4.5V, 10V | 110mOhm @ 2.5A, 10V | 3V @ 250µA | 7 nC @ 10 V | ±20V | 250 pF @ 24 V | - | 420mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 (TO-236) |
|
|
PMN30ENEAHPMN30ENEA/SOT457/SC-74 |
3,441 |
|
Tabla de datos |
- | SC-74, SOT-457 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 5.4A (Ta) | 4.5V, 10V | 30mOhm @ 5.4A, 10V | 2.5V @ 250µA | 11.7 nC @ 10 V | ±20V | 440 pF @ 20 V | - | 667mW (Ta), 7.5W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 6-TSOP |
|
BSS84MOSFET P-CH 50V 130MA SOT23-3 |
2,652 |
|
Tabla de datos |
- | - | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
FDN327N20V 2A 500MW [email protected],2A 1.5V@25 |
3,940 |
|
- |
- | TO-236-3, SC-59, SOT-23-3 | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 2A (Tc) | 1.8V, 4.5V | 70mOhm @ 2A, 4.5V | 1.5V @ 250µA | 3.6 nC @ 10 V | ±8V | 222 pF @ 10 V | - | 500mW (Tc) | 150°C (TJ) | - | - | Surface Mount | SOT-23 | |
.JPG)
|
TSM1N45CT B0GMOSFET N-CH 450V 500MA TO92 |
3,740 |
|
Tabla de datos |
- | TO-226-3, TO-92-3 (TO-226AA) | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 450 V | 500mA (Tc) | 10V | 4.25Ohm @ 250mA, 10V | 4.25V @ 250µA | 6.5 nC @ 10 V | ±30V | 235 pF @ 25 V | - | 2W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-92 |
|
PJL9401_R2_0000130V P-CHANNEL ENHANCEMENT MODE M |
4,880 |
|
Tabla de datos |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Not For New Designs | P-Channel | MOSFET (Metal Oxide) | 30 V | 3.5A (Ta) | 4.5V, 10V | 110mOhm @ 3A, 10V | 2.1V @ 250µA | 9.8 nC @ 10 V | ±20V | 396 pF @ 15 V | - | 2.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
|
PJL9403_R2_0000130V P-CHANNEL ENHANCEMENT MODE M |
2,178 |
|
Tabla de datos |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Not For New Designs | P-Channel | MOSFET (Metal Oxide) | 30 V | 3.6A (Ta) | 4.5V, 10V | 72mOhm @ 3.6A, 10V | 2.1V @ 250µA | 10 nC @ 10 V | ±20V | 417 pF @ 15 V | - | 2.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
DMP2067LSS-13MOSFET BVDSS: 8V~24V SO-8 T&R 2. |
3,253 |
|
Tabla de datos |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 5.4A (Ta), 12.9A (Tc) | 2.5V, 4.5V | 38mOhm @ 5A, 4.5V | 1.5V @ 250µA | 15.5 nC @ 8 V | ±8V | 1575 pF @ 10 V | - | 1.2W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SO |
|
|
DMP2067LVTQ-7MOSFET BVDSS: 8V~24V TSOT26 T&R |
4,730 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.2A (Ta) | 2.5V, 4.5V | 45mOhm @ 4.5A, 4.5V | 1.5V @ 250µA | 28 nC @ 8 V | ±8V | 1575 pF @ 10 V | - | 1.2W (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-26 |
|
DMN3020UFDF-13MOSFET N-CH 30V 15A 6UDFN |
2,888 |
|
Tabla de datos |
- | 6-UDFN Exposed Pad | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 15A (Tc) | 1.5V, 4.5V | 19mOhm @ 4.5A, 4.5V | 1V @ 250µA | 27 nC @ 8 V | ±12V | 1304 pF @ 15 V | - | 2.03W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | U-DFN2020-6 (Type F) |
|
|
ZXMN10A07FTCMOSFET N-CH 100V 700MA SOT23-3 |
4,254 |
|
Tabla de datos |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 700mA (Ta) | 6V, 10V | 700mOhm @ 1.5A, 10V | 4V @ 250µA | 2.9 nC @ 10 V | ±20V | 138 pF @ 50 V | - | 625mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 |
|
|
ZXMN6A07FTCMOSFET N-CH 60V 1.2A SOT23-3 |
4,604 |
|
Tabla de datos |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 1.2A (Ta) | 4.5V, 10V | 250mOhm @ 1.8A, 10V | 3V @ 250µA | 3.2 nC @ 10 V | ±20V | 166 pF @ 40 V | - | 625mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 |
|
FQNL1N50BBUMOSFET N-CH 500V 270MA TO92-3 |
2,258 |
|
Tabla de datos |
QFET® | TO-226-3, TO-92-3 Long Body, Formed Leads | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 270mA (Tc) | 10V | 9Ohm @ 135mA, 10V | 3.7V @ 250µA | 5.5 nC @ 10 V | ±30V | 150 pF @ 25 V | - | 1.5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-92-3 |
|
|
2N7002TCMOSFET N-CH 60V 115MA SOT23-3 |
4,482 |
|
Tabla de datos |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 115mA (Ta) | 5V, 10V | 7.5Ohm @ 500mA, 10V | 2.5V @ 250µA | - | ±20V | 50 pF @ 25 V | - | 330mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 |
|
|
DMN2009UFDF-13MOSFET BVDSS: 8V~24V U-DFN2020-6 |
4,630 |
|
Tabla de datos |
- | 6-UDFN Exposed Pad | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 12.8A (Ta) | 2.5V, 4.5V | 9mOhm @ 8.5A, 4.5V | 1.4V @ 250µA | 27.9 nC @ 10 V | ±12V | 1083 pF @ 10 V | - | 1.3W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | U-DFN2020-6 (Type F) |
|
|
DMN3066LVTQ-7MOSFET BVDSS: 25V~30V TSOT26 T&R |
4,706 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 3.6A (Ta) | 2.5V, 4.5V | 67mOhm @ 2.5A, 4.5V | 1.5V @ 250µA | 4 nC @ 4.5 V | ±12V | 328 pF @ 10 V | - | 900mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-26 |
|
|
SIL05N06HE3-TPMOSFET |
4,641 |
|
Tabla de datos |
- | SOT-23-6 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 5A (Ta) | 4.5V, 10V | 43mOhm @ 5A, 10V | 3V @ 250µA | 23.4 nC @ 10 V | ±20V | 1175 pF @ 30 V | - | 1.8W (Tj) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-23-6L |
|
AONR32314MOSFET N-CH 30V 17A/30A 8DFN |
4,085 |
|
Tabla de datos |
- | 8-SMD, Flat Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 17A (Ta), 30A (Tc) | 4.5V, 10V | 8.7mOhm @ 17A, 10V | 2.25V @ 250µA | 32 nC @ 10 V | ±20V | 1420 pF @ 15 V | - | 4.1W (Ta), 24W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-DFN (3x3) |
|
|
DMN2022UFDF-13MOSFET N-CH 20V 7.9A 6UDFN |
4,503 |
|
Tabla de datos |
- | 6-UDFN Exposed Pad | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 7.9A (Ta) | 1.5V, 4.5V | 22mOhm @ 4A, 4.5V | 1V @ 250µA | 18 nC @ 8 V | ±8V | 907 pF @ 10 V | - | 660mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | U-DFN2020-6 (Type F) |
