FET, MOSFET
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo FET | Tecnología | Voltaje de drenaje a fuente (Vdss) | Corriente: drenaje continuo (Id) a 25 °C | Voltaje de excitación (máx. Rds activado, mín. Rds activado) | Rds activado (máx.) a Id, Vgs | Vgs(th) (máx.) a Id | Carga de compuerta (Qg) (máx.) a Vgs | Vgs (máx.) | Capacitancia de entrada (Ciss) (máx.) a Vds | Característica FET | Disipación de potencia (máx.) | Temperatura de funcionamiento | Grado | Calificación | Tipo de montaje | Proveedor Dispositivo Paquete |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IXTK200N10PMOSFET N-CH 100V 200A TO264 |
221 |
|
Tabla de datos |
Polar | TO-264-3, TO-264AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 200A (Tc) | 10V | 7.5mOhm @ 100A, 10V | 5V @ 500µA | 240 nC @ 10 V | ±20V | 7600 pF @ 25 V | - | 800W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-264 (IXTK) |
|
IXTH150N15X4MOSFET N-CH 150V 150A TO247 |
388 |
|
Tabla de datos |
Ultra X4 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 150A (Tc) | 10V | 7.2mOhm @ 75A, 10V | 4.5V @ 250µA | 105 nC @ 10 V | ±20V | 5500 pF @ 25 V | - | 480W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-247 |
|
|
IXFK50N85XMOSFET N-CH 850V 50A TO264 |
170 |
|
Tabla de datos |
HiPerFET™, Ultra X | TO-264-3, TO-264AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 850 V | 50A (Tc) | 10V | 105mOhm @ 500mA, 10V | 5.5V @ 4mA | 152 nC @ 10 V | ±30V | 4480 pF @ 25 V | - | 890W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-264AA |
|
UF3C065040B3MOSFET N-CH 650V 41A TO263 |
443 |
|
Tabla de datos |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | - | 650 V | 41A (Tc) | 12V | 52mOhm @ 30A, 12V | 6V @ 10mA | 51 nC @ 15 V | ±25V | 1500 pF @ 100 V | - | 176W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
IXTT6N120MOSFET N-CH 1200V 6A TO268 |
232 |
|
Tabla de datos |
- | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 1200 V | 6A (Tc) | 10V | 2.6Ohm @ 3A, 10V | 5V @ 250µA | 56 nC @ 10 V | ±20V | 1950 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-268AA |
|
SCT4062KW7TL1200V, 24A, 7-PIN SMD, TRENCH-ST |
904 |
|
Tabla de datos |
- | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 24A (Tj) | 18V | 81mOhm @ 12A, 18V | 4.8V @ 6.45mA | 64 nC @ 18 V | +21V, -4V | 1498 pF @ 800 V | - | 93W | 175°C (TJ) | - | - | Surface Mount | TO-263-7L |
|
|
IXFH94N30P3MOSFET N-CH 300V 94A TO247 |
187 |
|
Tabla de datos |
HiPerFET™, Polar3™ | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 300 V | 94A (Tc) | 10V | 36mOhm @ 47A, 10V | 5V @ 4mA | 102 nC @ 10 V | ±20V | 5510 pF @ 25 V | - | 1040W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247 (IXTH) |
|
STWA12N120K5MOSFET N-CH 1200V 12A TO247 |
593 |
|
Tabla de datos |
MDmesh™ K5 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 1200 V | 12A (Tc) | 10V | 690mOhm @ 6A, 10V | 5V @ 100µA | 44.2 nC @ 10 V | ±30V | 1370 pF @ 100 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247 Long Leads |
|
STW75N60M6-4MOSFET N-CH 600V 72A TO247-4 |
531 |
|
Tabla de datos |
MDmesh™ M6 | TO-247-4 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 72A (Tc) | 10V | 36mOhm @ 36A, 10V | 4.75V @ 250µA | 106 nC @ 10 V | ±25V | 4850 pF @ 100 V | - | 446W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-4 |
|
|
IXFH15N100PMOSFET N-CH 1000V 15A TO247AD |
873 |
|
Tabla de datos |
HiPerFET™, Polar | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 1000 V | 15A (Tc) | 10V | 760mOhm @ 500mA, 10V | 6.5V @ 1mA | 97 nC @ 10 V | ±30V | 5140 pF @ 25 V | - | 543W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
IXFH60N65X2-4MOSFET N-CH 650V 60A TO247-4L |
298 |
|
Tabla de datos |
HiPerFET™, Ultra X2 | TO-247-4 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 60A (Tc) | 10V | 52mOhm @ 30A, 10V | 5V @ 4mA | 108 nC @ 10 V | ±30V | 6300 pF @ 25 V | - | 780W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-4L |
.jpg)
|
STW75N60DM6MOSFET N-CH 600V 72A TO247 |
338 |
|
Tabla de datos |
MDmesh™ DM6 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 72A (Tc) | - | - | - | - | ±25V | - | - | - | - | - | - | Through Hole | TO-247-3 |
|
SCT4045DW7HRTL750V, 31A, 7-PIN SMD, TRENCH-STR |
989 |
|
Tabla de datos |
- | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Active | N-Channel | SiCFET (Silicon Carbide) | 750 V | 31A (Tc) | 18V | 59mOhm @ 17A, 18V | 4.8V @ 8.89mA | 63 nC @ 18 V | +21V, -4V | 1460 pF @ 500 V | - | 93W | 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TO-263-7L |
|
SCT3060AW7TLSICFET N-CH 650V 38A TO263-7 |
1,175 |
|
Tabla de datos |
- | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Active | N-Channel | SiCFET (Silicon Carbide) | 650 V | 38A (Tc) | - | 78mOhm @ 13A, 18V | 5.6V @ 6.67mA | 58 nC @ 18 V | +22V, -4V | 852 pF @ 500 V | - | 159W | 175°C (TJ) | - | - | Surface Mount | TO-263-7 |
|
E3M0060065D60M 650V SIC AUTOMOTIVE MOSFET |
343 |
|
Tabla de datos |
- | TO-247-3 | Tube | Last Time Buy | N-Channel | SiCFET (Silicon Carbide) | 650 V | 37A (Tc) | 15V | 79mOhm @ 13.2A, 15V | 3.6V @ 3.6mA | 46 nC @ 15 V | +19V, -8V | 1170 pF @ 600 V | - | 131W (Tc) | -40°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Through Hole | TO-247-3 |
|
|
IXFH44N50Q3MOSFET N-CH 500V 44A TO247AD |
171 |
|
Tabla de datos |
HiPerFET™, Q3 Class | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 44A (Tc) | 10V | 140mOhm @ 22A, 10V | 6.5V @ 4mA | 93 nC @ 10 V | ±30V | 4800 pF @ 25 V | - | 830W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
IXTA150N15X4MOSFET N-CH 150V 150A TO263AA |
181 |
|
Tabla de datos |
Ultra X4 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 150A (Tc) | 10V | 6.9mOhm @ 75A, 10V | 4.5V @ 250µA | 105 nC @ 10 V | ±20V | 5500 pF @ 25 V | - | 480W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263AA |
|
FCH47N60F-F133MOSFET N-CH 600V 47A TO247-3 |
880 |
|
Tabla de datos |
SuperFET™ | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 47A (Tc) | 10V | 70mOhm @ 23.5A, 10V | 5V @ 250µA | 270 nC @ 10 V | ±30V | 8000 pF @ 25 V | - | 417W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
NTMFS011N15MCMOSFET N-CH 150V 10.7A/78A 8PQFN |
2,604 |
|
Tabla de datos |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 10.7A (Ta), 78A (Tc) | 8V, 10V | 11.5mOhm @ 35A, 10V | 4.5V @ 194µA | 46 nC @ 10 V | ±20V | 3592 pF @ 75 V | - | 2.7W (Ta), 147W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-PQFN (5x6) |
.jpg)
|
SCT4045DRHRC15750V, 34A, 4-PIN THD, TRENCH-STR |
492 |
|
Tabla de datos |
- | TO-247-4 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 750 V | 34A (Tc) | 18V | 59mOhm @ 17A, 18V | 4.8V @ 8.89mA | 63 nC @ 18 V | +21V, -4V | 1460 pF @ 500 V | - | 115W | 175°C (TJ) | Automotive | AEC-Q101 | Through Hole | TO-247-4L |
