FET, MOSFET
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo FET | Tecnología | Voltaje de drenaje a fuente (Vdss) | Corriente: drenaje continuo (Id) a 25 °C | Voltaje de excitación (máx. Rds activado, mín. Rds activado) | Rds activado (máx.) a Id, Vgs | Vgs(th) (máx.) a Id | Carga de compuerta (Qg) (máx.) a Vgs | Vgs (máx.) | Capacitancia de entrada (Ciss) (máx.) a Vds | Característica FET | Disipación de potencia (máx.) | Temperatura de funcionamiento | Grado | Calificación | Tipo de montaje | Proveedor Dispositivo Paquete |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SISS5708DN-T1-GE3N-CHANNEL 150 V (D-S) MOSFET POW |
6,000 |
|
Tabla de datos |
TrenchFET® | PowerPAK® 1212-8S | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 9.3A (Ta), 33.8A (Tc) | 7.5V, 10V | 23mOhm @ 10A, 10V | 4V @ 250µA | 20 nC @ 10 V | ±20V | 975 pF @ 75 V | - | 5W (Ta), 65.7W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® 1212-8S |
|
PSMN8R7-80BS,118MOSFET N-CH 80V 90A D2PAK |
5,282 |
|
Tabla de datos |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 90A (Tc) | 10V | 8.7mOhm @ 10A, 10V | 4V @ 1mA | 52 nC @ 10 V | ±20V | 3346 pF @ 40 V | - | 170W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
NP75N04YUK-E1-AYMOSFET N-CH 40V 75A 8HSON |
5,000 |
|
Tabla de datos |
- | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 75A (Tc) | 10V | 3.3mOhm @ 38A, 10V | 4V @ 250µA | 87 nC @ 10 V | ±20V | 5100 pF @ 25 V | - | 1W (Ta), 138W (Tc) | 175°C | - | - | Surface Mount | 8-HSON (5x5.4) |
|
IRFRC20TRLPBF-BE3MOSFET N-CH 600V 2A DPAK |
4,376 |
|
Tabla de datos |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 2A (Tc) | 10V | 4.4Ohm @ 1.2A, 10V | 4V @ 250µA | 18 nC @ 10 V | ±20V | 350 pF @ 25 V | - | 2.5W (Ta), 42W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252AA |
|
STP3NK80ZMOSFET N-CH 800V 2.5A TO220AB |
973 |
|
Tabla de datos |
SuperMESH™ | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 2.5A (Tc) | 10V | 4.5Ohm @ 1.25A, 10V | 4.5V @ 50µA | 19 nC @ 10 V | ±30V | 485 pF @ 25 V | - | 70W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
IPP055N08NF2SAKMA1TRENCH 40<-<100V |
139 |
|
Tabla de datos |
StrongIRFET™ 2 | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 18.5A (Ta), 99A (Tc) | 6V, 10V | 5.5mOhm @ 60A, 10V | 3.8V @ 55µA | 54 nC @ 10 V | ±20V | 2500 pF @ 40 V | - | 3.8W (Ta), 107W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | PG-TO220-3 |
|
SQJA26EP-T1_GE3AUTOMOTIVE N-CHANNEL 30 V (D-S) |
2,990 |
|
Tabla de datos |
- | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 410A (Tc) | 4.5V, 10V | 0.77mOhm @ 15A, 10V | 2.5V @ 250µA | 195 nC @ 10 V | ±20V | 9778 pF @ 25 V | - | 500W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
NTMYS8D0N04CTWGMOSFET N-CH 40V 16A/49A 4LFPAK |
2,269 |
|
Tabla de datos |
- | SOT-1023, 4-LFPAK | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 16A (Ta), 49A (Tc) | 10V | 8.1mOhm @ 15A, 10V | 3.5V @ 30µA | 10 nC @ 10 V | ±20V | 625 pF @ 25 V | - | 3.8W (Ta), 38W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK4 (5x6) |
|
|
RJL5014DPP-A0#T2ABU / MOSFET HV |
3,290 |
|
Tabla de datos |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 19A (Ta) | 10V | 400mOhm @ 9.5A, 10V | 4V @ 1mA | 43 nC @ 10 V | ±30V | 1700 pF @ 25 V | - | 35W (Ta) | 150°C | - | - | Through Hole | TO-220FN |
|
SIR516DP-T1-RE3N-CHANNEL 100 V (D-S) MOSFET POW |
5,280 |
|
Tabla de datos |
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 16.8A (Ta), 63.7A (Tc) | 7.5V, 10V | 8mOhm @ 10A, 10V | 4V @ 250µA | 27 nC @ 10 V | ±20V | 1920 pF @ 50 V | - | 5W (Ta), 71.4W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
STF6N62K3MOSFET N-CH 620V 5.5A TO220FP |
852 |
|
Tabla de datos |
SuperMESH3™ | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 620 V | 5.5A (Tc) | 10V | 1.28Ohm @ 2.8A, 10V | 4.5V @ 50µA | 34 nC @ 10 V | ±30V | 875 pF @ 50 V | - | 30W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
|
MCAC90N10Y-TPMOSFET N-CH 100 90A DFN5060 |
9,968 |
|
- |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 90A | - | 5.2mOhm @ 20A, 10V | 4V @ 250µA | 66 nC @ 10 V | ±20V | 4600 pF @ 50 V | - | 120W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DFN5060 |
|
|
NP90N04VLK-E1-AYMOSFET N-CH 40V 90A TO252 |
5,000 |
|
Tabla de datos |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 90A (Tc) | 4.5V, 10V | 2.8mOhm @ 45A, 10V | 2.5V @ 250µA | 102 nC @ 10 V | ±20V | 5700 pF @ 25 V | - | 1.2W (Ta), 147W (Tc) | 175°C | - | - | Surface Mount | TO-252 (MP-3ZP) |
|
|
MCAC95N065Y-TPMOSFET N-CH 65 95A DFN5060 |
4,895 |
|
Tabla de datos |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 65 V | 95A (Tc) | 4.5V, 10V | 2.5mOhm @ 20A, 10V | 2.2V @ 250µA | 93 nC @ 10 V | ±20V | 5950 pF @ 25 V | - | 120W (Tj) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DFN5060 |
|
PSMN2R0-40YLDXMOSFET N-CH 40V 180A LFPAK56 |
3,215 |
|
Tabla de datos |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 180A (Tc) | 4.5V, 10V | 2.1mOhm @ 25A, 10V | 2.05V @ 1mA | 92 nC @ 10 V | ±20V | 6581 pF @ 20 V | Schottky Diode (Body) | 166W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
|
IPB029N06NF2SATMA1TRENCH 40<-<100V |
1,613 |
|
Tabla de datos |
StrongIRFET™2 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 26A (Ta), 120A (Tc) | 6V, 10V | 2.9mOhm @ 70A, 10V | 3.3V @ 80µA | 102 nC @ 10 V | ±20V | 4600 pF @ 30 V | - | 3.8W (Ta), 150W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PG-TO263-3 |
|
IPD90N06S404ATMA2MOSFET N-CH 60V 90A TO252-31 |
8,004 |
|
Tabla de datos |
OptiMOS™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 90A (Tc) | 10V | 3.8mOhm @ 90A, 10V | 4V @ 90µA | 128 nC @ 10 V | ±20V | 10400 pF @ 25 V | - | 150W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PG-TO252-3-11 |
|
AOD360A70MOSFET N-CH 700V 12A TO252 |
5,089 |
|
Tabla de datos |
aMOS5™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 700 V | 12A (Tc) | 10V | 360mOhm @ 6A, 10V | 4V @ 250µA | 22.5 nC @ 10 V | ±20V | 1360 pF @ 100 V | - | 138W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
|
STF3N80K5MOSFET N-CH 800V 2.5A TO220FP |
1,218 |
|
Tabla de datos |
SuperMESH5™ | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 2.5A (Tc) | 10V | 3.5Ohm @ 1A, 10V | 5V @ 100µA | 9.5 nC @ 10 V | ±30V | 130 pF @ 100 V | - | 20W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
R6509KND3TL1HIGH-SPEED SWITCHING, NCH 650V 9 |
2,390 |
|
Tabla de datos |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 9A (Tc) | 10V | 585mOhm @ 2.8A, 10V | 5V @ 230µA | 16.5 nC @ 10 V | ±20V | 540 pF @ 25 V | - | 94W (Tc) | 150°C (TJ) | - | - | Surface Mount | TO-252 |
