FET, MOSFET
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo FET | Tecnología | Voltaje de drenaje a fuente (Vdss) | Corriente: drenaje continuo (Id) a 25 °C | Voltaje de excitación (máx. Rds activado, mín. Rds activado) | Rds activado (máx.) a Id, Vgs | Vgs(th) (máx.) a Id | Carga de compuerta (Qg) (máx.) a Vgs | Vgs (máx.) | Capacitancia de entrada (Ciss) (máx.) a Vds | Característica FET | Disipación de potencia (máx.) | Temperatura de funcionamiento | Grado | Calificación | Tipo de montaje | Proveedor Dispositivo Paquete |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RSQ025P03HZGTRMOSFET P-CH 30V 2.5A TSMT6 |
1,003 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 2.5A (Ta) | 4V, 10V | 110mOhm @ 2.5A, 10V | 2.5V @ 1mA | 4.4 nC @ 5 V | ±20V | 320 pF @ 10 V | - | 950mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSMT6 (SC-95) |
|
SQJA64EP-T1_BE3N-CHANNEL 60-V (D-S) 175C MOSFET |
17,989 |
|
Tabla de datos |
TrenchFET® | PowerPAK® SO-8 Dual | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 15A (Tc) | 10V | 32mOhm @ 4A, 10V | 3.5V @ 250µA | 12 nC @ 10 V | ±20V | 670 pF @ 25 V | - | 45W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PowerPAK® SO-8 Dual |
|
SIRA26DP-T1-RE3MOSFET N-CH 25V 60A PPAK SO-8 |
2,499 |
|
Tabla de datos |
TrenchFET® Gen IV | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 60A (Tc) | 4.5V, 10V | 2.65mOhm @ 15A, 10V | 2.5V @ 250µA | 44 nC @ 10 V | +16V, -12V | 2247 pF @ 10 V | - | 43.1W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
DMTH46M7SFVWQ-7MOSFET BVDSS: 31V~40V POWERDI333 |
1,325 |
|
Tabla de datos |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 16.3A (Ta), 67.2A (Tc) | 10V | 7.4mOhm @ 20A, 10V | 4V @ 250µA | 14.8 nC @ 10 V | ±20V | 1315 pF @ 20 V | - | 3.2W (Ta), 54.5W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount, Wettable Flank | PowerDI3333-8 (SWP) Type UX |
|
BUK7M21-40EXMOSFET N-CH 40V 33A LFPAK33 |
207 |
|
Tabla de datos |
TrenchMOS™ | SOT-1210, 8-LFPAK33 (5-Lead) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 33A (Tc) | 10V | 21mOhm @ 10A, 10V | 4V @ 1mA | 10.7 nC @ 10 V | ±20V | 593 pF @ 25 V | - | 44W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK33 |
|
RS1E240BNTBMOSFET N-CH 30V 24A 8HSOP |
7,388 |
|
Tabla de datos |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 24A (Ta), 40A (Tc) | 4.5V, 10V | 3.2mOhm @ 24A, 10V | 2.5V @ 1mA | 70 nC @ 10 V | ±20V | 3900 pF @ 15 V | - | 3W (Ta), 30W (Tc) | 150°C (TJ) | - | - | Surface Mount | 8-HSOP |
|
|
ISZ15EP15LMATMA1TRENCH >=100V |
4,871 |
|
Tabla de datos |
- | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
DMNH6042SPSQ-13MOSFET N-CH 60V 24A PWRDI5060-8 |
2,485 |
|
Tabla de datos |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 24A (Tc) | 4.5V, 10V | 50mOhm @ 5.1A, 10V | 3V @ 250µA | 8.8 nC @ 10 V | ±20V | 584 pF @ 25 V | - | 2.9W (Ta) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PowerDI5060-8 |
|
|
RTQ025P02HZGTRMOSFET P-CH 20V 2.5A TSMT6 |
2,120 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.5A (Ta) | 2.5V, 4.5V | 100mOhm @ 2.5A, 4.5V | 2V @ 1mA | 6.4 nC @ 4.5 V | ±12V | 580 pF @ 10 V | - | 950mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSMT6 (SC-95) |
|
|
RTQ045N03HZGTRMOSFET N-CH 30V 4.5A TSMT6 |
1,908 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 4.5A (Ta) | 2.5V, 4.5V | 43mOhm @ 4.5A, 4.5V | 1.5V @ 1mA | 10.7 nC @ 4.5 V | ±12V | 540 pF @ 10 V | - | 950mW (Ta) | 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSMT6 (SC-95) |
;;6.jpg)
|
RF4E080BNTRMOSFET N-CH 30V 8A HUML2020L8 |
1,831 |
|
Tabla de datos |
- | 8-PowerUDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8A (Ta) | 4.5V, 10V | 17.6mOhm @ 8A, 10V | 2V @ 250µA | 14.5 nC @ 10 V | ±20V | 660 pF @ 15 V | - | 2W (Ta) | 150°C (TJ) | - | - | Surface Mount | HUML2020L8 |
|
|
PSMN3R9-25MLC,115MOSFET N-CH 25V 70A LFPAK33 |
1,513 |
|
Tabla de datos |
- | SOT-1210, 8-LFPAK33 (5-Lead) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 70A (Tc) | 4.5V, 10V | 4.15mOhm @ 25A, 10V | 2.15V @ 1mA | 21.5 nC @ 10 V | ±20V | 1524 pF @ 12.5 V | - | 69W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK33 |
|
ISZ040N03L5ISATMA1MOSFET N-CH 30V 18A/40A TSDSON |
19,685 |
|
Tabla de datos |
OptiMOS™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A (Ta), 40A (Tc) | 4.5V, 10V | 4mOhm @ 30A, 10V | 2V @ 250µA | 17 nC @ 10 V | ±20V | 1100 pF @ 15 V | - | 2.1W (Ta), 37W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSDSON-8-FL |
|
|
SQJA70EP-T1_BE3N-CHANNEL 100-V (D-S) 175C MOSFE |
5,977 |
|
Tabla de datos |
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 14.7A (Tc) | 10V | 95mOhm @ 4A, 10V | 3.5V @ 250µA | 7 nC @ 10 V | ±20V | 220 pF @ 25 V | - | 27W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PowerPAK® SO-8 |
|
SQS405CENW-T1_GE3AUTOMOTIVE P-CHANNEL 12 V (D-S) |
5,813 |
|
Tabla de datos |
TrenchFET® | PowerPAK® 1212-8 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 12 V | 16A (Tc) | 2.5V, 4.5V | 15mOhm @ 13.5A, 4.5V | 1V @ 250µA | 81 nC @ 8 V | ±8V | 3050 pF @ 6 V | - | 39W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PowerPAK® 1212-8 |
|
RTF015P02TLMOSFET P-CH 20V 1.5A TUMT3 |
5,800 |
|
Tabla de datos |
- | 3-SMD, Flat Leads | Tape & Reel (TR) | Not For New Designs | P-Channel | MOSFET (Metal Oxide) | 20 V | 1.5A (Ta) | 2.5V, 4.5V | 135mOhm @ 1.5A, 4.5V | 2V @ 1mA | 5.2 nC @ 4.5 V | ±12V | 560 pF @ 10 V | - | 800mW (Ta) | 150°C (TJ) | - | - | Surface Mount | TUMT3 |
|
TPH4R803PL,LQMOSFET N-CH 30V 48A 8SOP |
4,989 |
|
Tabla de datos |
U-MOSIX-H | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 48A (Tc) | 4.5V, 10V | 4.8mOhm @ 24A, 10V | 2.1V @ 200µA | 22 nC @ 10 V | ±20V | 1975 pF @ 15 V | - | 830mW (Ta), 69W (Tc) | 175°C | - | - | Surface Mount | 8-SOP Advance (5x5) |
|
|
SQJA68EP-T1_BE3N-CHANNEL 100-V (D-S) 175C MOSFE |
2,196 |
|
Tabla de datos |
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 14A (Tc) | 4.5V, 10V | 92mOhm @ 4A, 10V | 2.5V @ 250µA | 8 nC @ 10 V | ±20V | 280 pF @ 25 V | - | 45W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PowerPAK® SO-8 |
|
SQ3410EV-T1_BE3N-CHANNEL 30-V (D-S) 175C MOSFET |
8,262 |
|
Tabla de datos |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8A (Tc) | 4.5V, 10V | 17.5mOhm @ 5A, 10V | 2.5V @ 250µA | 21 nC @ 10 V | ±20V | 1005 pF @ 15 V | - | 5W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 6-TSOP |
|
MCQ18N03-TPN-CHANNEL MOSFET,SOP-8 |
7,883 |
|
Tabla de datos |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A | 4.5V, 10V | 5mOhm @ 18A, 10V | 2.5V @ 250µA | 42 nC @ 10 V | ±20V | 1950 pF @ 15 V | - | 2.5W | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-SOP |
