FET, MOSFET
| Foto | N.º de Parte del Fabricante | Disponibilidad | Cantidad | Hoja de Datos | Serie | Paquete/Caja | Embalaje | Estado del producto | Tipo FET | Tecnología | Voltaje de drenaje a fuente (Vdss) | Corriente: drenaje continuo (Id) a 25 °C | Voltaje de excitación (máx. Rds activado, mín. Rds activado) | Rds activado (máx.) a Id, Vgs | Vgs(th) (máx.) a Id | Carga de compuerta (Qg) (máx.) a Vgs | Vgs (máx.) | Capacitancia de entrada (Ciss) (máx.) a Vds | Característica FET | Disipación de potencia (máx.) | Temperatura de funcionamiento | Grado | Calificación | Tipo de montaje | Proveedor Dispositivo Paquete |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SIHG17N60D-E3MOSFET N-CH 600V 17A TO247AC |
4,223 |
|
Tabla de datos |
- | TO-247-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 17A (Tc) | 10V | 340mOhm @ 8A, 10V | 5V @ 250µA | 90 nC @ 10 V | ±30V | 1780 pF @ 100 V | - | 277.8W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
|
SIHG17N60D-GE3MOSFET N-CH 600V 17A TO247AC |
4,421 |
|
Tabla de datos |
- | TO-247-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 17A (Tc) | 10V | 340mOhm @ 8A, 10V | 5V @ 250µA | 90 nC @ 10 V | ±30V | 1780 pF @ 100 V | - | 277.8W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
IPI06CN10N GMOSFET N-CH 100V 100A TO262-3 |
4,435 |
|
Tabla de datos |
OptiMOS™ | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 100A (Tc) | 10V | 6.5mOhm @ 100A, 10V | 4V @ 180µA | 139 nC @ 10 V | ±20V | 9200 pF @ 50 V | - | 214W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | PG-TO262-3 |
|
STW17N62K3MOSFET N-CH 620V 15.5A TO247-3 |
3,911 |
|
Tabla de datos |
SuperMESH3™ | TO-247-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 620 V | 15.5A (Tc) | 10V | 380mOhm @ 7.5A, 10V | 4.5V @ 100µA | 94 nC @ 10 V | ±30V | 2500 pF @ 50 V | - | 190W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
AOW2500MOSFET N-CH 150V 11.5/152A TO262 |
4,252 |
|
Tabla de datos |
- | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 11.5A (Ta), 152A (Tc) | 6V, 10V | 6.2mOhm @ 20A, 10V | 3.5V @ 250µA | 136 nC @ 10 V | ±20V | 6460 pF @ 75 V | - | 2.1W (Ta), 375W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-262 |
|
|
IPI60R165CPAKSA1MOSFET N-CH 650V 21A TO262-3 |
4,527 |
|
Tabla de datos |
CoolMOS™ | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 650 V | 21A (Tc) | 10V | 165mOhm @ 12A, 10V | 3.5V @ 790µA | 52 nC @ 10 V | ±20V | 2000 pF @ 100 V | - | 192W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO262-3 |
|
IRL2505STRLMOSFET N-CH 55V 104A D2PAK |
4,876 |
|
Tabla de datos |
HEXFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 104A (Tc) | 4V, 10V | 8mOhm @ 54A, 10V | 2V @ 250µA | 130 nC @ 5 V | ±16V | 5000 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
|
IRL2505STRRMOSFET N-CH 55V 104A D2PAK |
2,800 |
|
Tabla de datos |
HEXFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 104A (Tc) | 4V, 10V | 8mOhm @ 54A, 10V | 2V @ 250µA | 130 nC @ 5 V | ±16V | 5000 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
|
IRL2910STRLMOSFET N-CH 100V 55A D2PAK |
3,375 |
|
Tabla de datos |
HEXFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 55A (Tc) | 4V, 10V | 26mOhm @ 29A, 10V | 2V @ 250µA | 140 nC @ 5 V | ±16V | 3700 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
PSMN5R0-100PS,127MOSFET N-CH 100V 120A TO220AB |
3,475 |
|
Tabla de datos |
- | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 10V | 5mOhm @ 25A, 10V | 4V @ 1mA | 170 nC @ 10 V | ±20V | 9900 pF @ 50 V | - | 338W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
PSMN3R5-80PS,127MOSFET N-CH 80V 120A TO220AB |
2,247 |
|
Tabla de datos |
- | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 80 V | 120A (Tc) | 10V | 3.5mOhm @ 25A, 10V | 4V @ 1mA | 139 nC @ 10 V | ±20V | 9961 pF @ 40 V | - | 338W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
PSMN4R3-100PS,127MOSFET N-CH 100V 120A TO220AB |
4,814 |
|
Tabla de datos |
- | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 10V | 4.3mOhm @ 25A, 10V | 4V @ 1mA | 170 nC @ 10 V | ±20V | 9900 pF @ 50 V | - | 338W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
PSMN2R0-60PSRQMOSFET N-CH 60V 120A TO220AB |
3,326 |
|
Tabla de datos |
- | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 120A (Tc) | 10V | 2.2mOhm @ 25A, 10V | 4V @ 1mA | 192 nC @ 10 V | ±20V | 13500 pF @ 30 V | - | 338W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
IRL1004STRLMOSFET N-CH 40V 130A D2PAK |
3,190 |
|
Tabla de datos |
HEXFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 130A (Tc) | 4.5V, 10V | 6.5mOhm @ 78A, 10V | 1V @ 250µA | 100 nC @ 4.5 V | ±16V | 5330 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | D2PAK |
|
IXTA12N65X2MOSFET N-CH 650V 12A TO263AA |
3,973 |
|
Tabla de datos |
Ultra X2 | TO-263-3, D2PAK (2 Leads + Tab), Variant | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 12A (Tc) | 10V | 300mOhm @ 6A, 10V | 5V @ 250µA | 17 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 180W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263AA |
|
IXFA4N100P-TRLMOSFET N-CH 1000V 4A TO263 |
2,292 |
|
- |
HiPerFET™, Polar | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 1000 V | 4A (Tc) | 10V | 3.3Ohm @ 2A, 10V | 6V @ 250µA | 26 nC @ 10 V | ±20V | 1456 pF @ 25 V | - | 150W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
IRF5305LMOSFET P-CH 55V 31A TO262 |
3,545 |
|
Tabla de datos |
HEXFET® | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Obsolete | P-Channel | MOSFET (Metal Oxide) | 55 V | 31A (Tc) | 10V | 60mOhm @ 16A, 10V | 4V @ 250µA | 63 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 3.8W (Ta), 110W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-262 |
|
FQH70N10MOSFET N-CH 100V 70A TO247-3 |
2,848 |
|
Tabla de datos |
QFET® | TO-247-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 70A (Tc) | 10V | 23mOhm @ 35A, 10V | 4V @ 250µA | 110 nC @ 10 V | ±25V | 3300 pF @ 25 V | - | 214W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-247-3 |
|
PSMN1R1-30PL,127MOSFET N-CH 30V 120A TO220AB |
4,604 |
|
Tabla de datos |
- | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 120A (Tc) | 4.5V, 10V | 1.3mOhm @ 25A, 10V | 2.2V @ 1mA | 243 nC @ 10 V | ±20V | 14850 pF @ 15 V | - | 338W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
IRF2204LPBFMOSFET N-CH 40V 170A TO262 |
3,477 |
|
Tabla de datos |
HEXFET® | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 170A (Tc) | 10V | 3.6mOhm @ 130A, 10V | 4V @ 250µA | 200 nC @ 10 V | ±20V | 5890 pF @ 25 V | - | 200W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-262 |
